The color UV inkjet printer - C5000 model independently developed by the WQ logo has a variety of commonly used font libraries built in. In addition, it supports font import function. Users can import their own fonts, support Pinyin input method, handwriting input method, etc. The software provides interfaces to support secondary development. The printing head is a double row ink inlet pipe, with fine ink dots. It is a fully enclosed gray scale printing head, which is waterproof and anti-aging. The printing head has a built-in thermostatic system, and the printing voltage can be adjusted with the temperature to obtain a more stable printing state.The color UV inkjet printer - C5000 model independently developed by the WQ logo has a variety of commonly used font libraries built in. In addition, it supports font import function. Users can import their own fonts, support Pinyin input method, handwriting input method, etc. The software provides interfaces to support secondary development. The printing head is a double row ink inlet pipe, with fine ink dots. It is a fully enclosed gray scale printing head, which is waterproof and anti-aging. The printing head has a built-in thermostatic system, and the printing voltage can be adjusted with the temperature to obtain a more stable printing state. Functional features ● System: industrial Android system, high-quality experience ● Interface: 21 inch high-definition LCD ● Nozzle: imported industrial piezoelectric nozzle, supporting multi head and splicing expansion ● Data: online variable data printing ● Ink supply: intelligent electronic negative pressure ink supply system ● Maintenance: non-stop ink change, one button maintenance function ● Expansion: customization and development of non-standard functions

Product model	Inkjet Coding Machine ---C5000
Printing head parameters	Print head type: all imported industrial piezoelectric nozzles Print head material: all steel Number of printing head: 2pcs Max printing height: 54.1mm Number of Jet nozzles: 1280x2pcs Jet nozzle column spacing: 0.55mm Jet nozzle spacing: about 0.1693mm/column Ink drop: 7~35Pl variable ink drop Jet nozzle rows: 8 rows
Display screen	Size: 21inch Capacitive touch screen
Operating input	Wireless mouse; Keyboard input operation
Hardware interface	USB2.0 interfacel RS232 interfacel Encoder interface Flip-flop interface
Working environment	Working temperature: 0 ℃-45 ℃ (best 10 ℃ ~ 32 ℃) Humidity:15%-75% l Protection requirements: good grounding
Size	Power supply: AC220V/50HZ System power consumption: Rated power consumption 120W
Software system	Variable color, Data printing system
Printing color	Monochrome printing or color printing
Ink Type	Eco-friendly UV ink
Technical specification	Printing head lifetime: 10 billion times of ink ejectionl Printing distance: 0mm~5mm, best 0~3mml Printing speed: 0~80 m/min (ink volume 1) (decided by material/resolution/environment/platform)l Longitudinal accuracy of printing head: 300dpil Horizontal accuracy of printing head: 600dpi-1200dpi Printing direction: adjustable forward, reverse, vertical downward; adjustable up and down in the program, flip left and right Curing type: LED-UV curing
Features	Image printing: Import PNG, JPG, BMP images through the U disk for printing.l Material type: aluminum plate, ceramic tile, glass, wood, metal sheet, acrylic sheet, plastic, leather and other flat materials, as well as bags, paper boxes, paper, stainless steel, iron mouth and other products.l Applicable products: such as mobile phone display screen, beverage bottle caps, food packaging bags, medicine boxes, plastic doors and Windows, aluminum alloy, battery, plastic pipes, steel plates, circuit boards, chips, woven bags, eggs, brake pads, mobile phone shell carton, motor, transformer, water meter inner plate, gypsum board, PCB circuit board, outer packaging, etc.l Printing content: variable color picture, variable color bar code, variable color LOGO, the system supports printing one-dimensional bar code, two-dimensional bar code, drug supervision code, traceability code, database and other content. And can flexibly design layout, content, printing position.

Application Industry It is widely used in food, medicine, daily chemical, label printing, card printing, packaging printing, medical, electronic, hardware and other industries, and can be used for marking printing on flat materials such as aluminum plate, ceramic tile, glass, wood, metal sheet, acrylic plate, plastic, leather, bags, cartons and other products; Applicable Products Such as mobile phone display screen, beverage bottle cap, food outer packaging bag, medicine box, plastic steel door and window, aluminum alloy, battery, plastic pipe, steel plate, circuit board, chip, woven bag, egg, brake pad, mobile phone shell carton, motor, transformer, water meter inner plate, gypsum board, PCB wiring board, outer packaging, etc; Printing Content Variable color picture, variable color barcode, variable color LOGO, and the system supports spray printing of one-dimensional barcode, two-dimensional barcode, drug supervision code, traceability code, database, etc. And it can flexibly design the layout, content and printing position.
